69 GB
Resolution (horizontal TV lines): 1280 x 720 pixel
Picture angle: h 65 °, v 38 °
Detection range
Motion detector: 90° x 5 m
Infrared range (night vision
mode black / white): 6 IR LEDs up to 8 m range
Light sensitivity: 1–8 LUX
Operating temperature: -10°C – +50 °C
Humidity during use: 40–80 % RH
Storage temperature: -10 °C –
~
+60 °C
Humidity during storage: 20–90 % RH
Connections: Ethernet (10 / 100 Base-T / Base-TX);
WLAN IEEE 802.11 b / g / n
Frequency: 2.4 GHz
Protection class: IP66 (dust- and hose-proof)
Weight: approx. 540 g (camera with base,
aerial and sun screen)
Power supply (for dry indoor use only):
Model / type: CS9C050150FGF
Manufacturer: CSEC
Input voltage / frequency: 100–240 V
~
, 50 / 60 Hz
Input current: 500 mA
Output voltage: 5 V DC
Output current: 1.5 A
Protection class: II /
Scope of delivery
Remove all parts from packaging and dispose of all packaging material.
Please contact customer service if parts are missing or damaged.
