8 GB/IE
liable for damage caused by improper use. The product is not intended
for commercial use.
Description of parts
(see front flap)
1
camera
2
pre-drilled holes
3
locking screw
4
extension cable
5
screws
6
dowel
7
mains adapter
Technical Data
Camera:
Type of device: UK 8 B1
Measurements: approx. 4.3 x 9.0 x 7.0 cm (W x H x D)
Image sensor: ¼
CMOS, 640 x 480 pixel
Focal length: 6 mm
Resolution (horizontal TV lines): 380
Picture angle: 35°
Infrared LED lighting (each): 850 nm, 1.5 V, 60 mW
Infrared range (Night vision
mode black and white): 5 m
Light sensitivity: 0.5 LUX
Electronic shutter speed: 1/50 sec.
~
1/100000 sec.
S/R ratio: >48dB
Operating temperature: -10°C – +50 °C
