SMC Corporation LECP1 series User Manual

- 9 -
No. JXC※-OMU0029-A
2.4 Option
(1) Actuator cable (5m or less)
ＬＥ-ＣＰ- □ -□
Cable length (L)
Actuator cable type
Electric actuator side
(2) Actuator cable (8-20m)
ＬＥ-ＣＰ-□
Cable length (L)
*1) Produced upon receipt of
order.
Only Robotic type cable
can be selected.
Electric actuator side
signal
Terminal no.
A
B-1
A
A-1
B
B-2
B
A-2
COM-A/COM
B-3
COM-B/ -
A-3
Vcc
B-4
GND
A-4
A
B-5
A
A-5
B
B-6
B
A-6
signal
Terminal no.
A
B-1
A
A-1
B
B-2
B
A-2
COM-A / COM
B-3
COM-B / -
A-3
Vcc
B-4
GND
A-4
A
B-5
A
A-5
B
B-6
B
A-6
Cable color
Terminal no.
Brown
2
Red
1
Orange
6
Yellow
5
Green
3
Blue
4
Cable color
Terminal no.
Brown
12
Black
13
Red
7
Black
6
Orange
9
Black
8
-
3
Shield
①
②
③
8
8m
*1)
A
10m
*1)
B
15m
*1)
C
20m
*1)
Controller side
1
1.5m
3
3m
5
5m
Shield
①
②
③
Cable color
Terminal no.
Brown
2
Red
1
Orange
6
Yellow
5
Green
3
Blue
4
Cable color
Terminal no.
Brown
12
Black
13
Red
7
Black
6
Orange
9
Black
8
-
3
Nil
Robotic type cable
S
Standard cable
Controller side
