SMC Corporation LECP1 series User Manual

- 8 -
No. JXC※-OMU0029-A
2.3 How to Order
The part number construction for this product is as follows:
Controller
ＬＥＣＰ１ Ｎ□□－□
Controller Electric actuator model
Compatible
Number of step data
Parallel I/O type Option
I/O cable length
1.5 m power cable is included
Electric actuator＋Controller
ＬＥＨＺ１０ＬＫ２－ ４ＡＦ－Ｒ１１Ｎ □□
Electric actuator type Option
Compile the product number while referring to the How to Order
section in the electric actuator catalogue. Please refer to the table
below for the corresponding electric actuator.
I/O cable length
*1)
Controller
*1) An I/O cable cannot be specified for an actuator without a controller.
The LECP6 series I/O cable cannot be used because the specifications are different.
Caution
Single controllers are also shipped after setting the electric actuator specification parameters.
Check that the combination of the controller and the electric actuator is correct before use.
Example: For LEHZ10LK2-4AF-R11N1,
specify LEHZ10LK2-4.
(Enter from the electric actuator part number
“LE” to “stroke / rotating angle”)
Applicable electric actuators
Electric gripper：LEH Series
Electric slide table：LES Series
Electric actuator / Rod type：LEY Series
Electric actuator / Slider type：LEF Series
Electric actuator / Low profile slider type：LEM Series
Electric actuator / Rotary type：LER Series
Electric actuator / Guide rod Slider：LEL Series
Electric actuator / Miniature type：LEP Series
Nil
No controller
＊
1N
With programless controller (NPN)
1P
With programless controller (PNP)
Nil
None
1
1.5 m
3
3 m
5
5 m
P
Step motor (Servo / 24 VDC)
1
14 points (Programless)
N
NPN type
P
PNP type
Nil
None
1
1.5 m
3
3 m
5
5 m
Nil
Screw mounting
D
DIN rail mounting
