C-1
A
PPENDIX
C
S
PECIFICATIONS
IEEE Standards
IEEE 802.3 10 BASE-T Ethernet
IEEE 802.3u 100 BASE-TX Fast Ethernet
IEEE 802.3, 802.3u, 802.11g, 802.1D
ITU G.dmt
ITU G.Handshake
ITU T.413 issue 2 - ADSL full rate
LAN Interface
4 RJ-45 10 BASE-T/100 BASE-TX ports
Auto-negotiates the connection speed to 10 Mbps Ethernet or 100 Mbps
Fast Ethernet, and the transmission mode to half-duplex or full-duplex
WAN Interface
1 ADSL RJ-45 port
Indicator Panel
LAN 1~4, WLAN, PPPoE/DSL, WAN, Power
Dimensions
145 x 95 x 36 mm (5.70 x 3.74 x 1.41 in)
Weight
0.175 kg (0.469 lbs)
Input Power
9 V 1 A
Power Consumption
9 Watts maximum
