I
NSTALLATION
2-6
Wall-Mount Installation
There are two wall-mount holes at the bottom of the Barricade. Before
drilling two holes into the wall, make sure the holes are 112 mm apart.
1. Choose a suitable location for the Barricade.
Note: It should be accessible for installing, cabling and maintaining the
device.
2. Measure the distance of the two wall-mount holes.
3. Drill two holes into the wall.
4. Insert a screw into each hole.
Note: Leave 5 mm exposed of the screw head.
5. Attach the Barricade to the wall with two wall-mount slots, and then
slide the device down until the screws fit firmly into the slots of the
device.
112 mm
