-16-

EX※※-OMR1012

Mounting and Installation

■

Wiring

Connector pin assignment

Configuration

BUS IN/BUS OUT

Pin No. Signal name

1 TX+

2 RX+

3 TX-

4 RX-

●Precautions for handling

Be sure to fit a seal cap on any unused connectors. Proper use of the seal cap enables the

enclosure to achieve IP67 specification.
