SMC Networks EX600 Series Opration Manual

-26-
EX※※-OMR1012
Specification
■Specifications
Model EX600-SEN5-X22
Protocol EtherNet/IP
TM
(IEEE802.3)
Transmission medium
Standard EtherNet cable
(CAT5 or more, 100BASE-TX)
Transmission speed 10/100 Mbps (Auto negotiation)
Transmission type Full duplex/Half duplex (Auto negotiation)
Setting by SI unit switch
IP address setting range
Via DHCP server : Arbitrary address
Device information
Vendor ID: 7 (SMC Corporation)
Product type: 12 (Communication Adapter)
Product code: 185
Network topology
Star: Applicable
Linear Bus: Applicable
Ring (including DLR): Applicable
Communication
EtherNet/IP QuickConnect Supported
Applicable valve series
Solenoid valve with surge voltage suppressor 24 VDC,
1.0 W or less (SMC)
Valve output
Max. number of solenoid valves
32 outputs
PNP (Negative common)
Operating temperature range -10 to 50
o
C
Storage temperature range -20 to 60
o
C
Operating humidity range 35 to 85% RH (no dew condition)
Withstand voltage 500 VAC for 1 minute between external terminals and FE
Insulation resistance 500 VDC, 10 MΩ or more between external terminals and FE
Vibration resistance
10 to 57 Hz: constant amplitude 0.75 mm p-p
57 to 150 Hz: constant acceleration 49 m/s
2
for 2 hours in each direction X, Y and Z respectively
(De-energized)
Environment
Impact resistance
147 m/s
2
3 times in each directions of X, Y and Z respectively
(De-energized)
Standard CE marking, UL (CSA), RoHS
Weight 300 g or less
