Specification
■Specifications
Model EX600-ED2- EX600-ED3-
Power connector M12 (5 pin) Plug 7/8 inch (5 pin) Plug
Power supply
(Control and input)
24 VDC ±10% Class2, 2 A 24 VDC ±10%, 8 A
Power
Power supply (Output) 24 VDC +10/-5% Class2, 2 A 24 VDC +10/-5%, 8 A
Enclosure IP67 (With manifold assembled)

Operating temperature range -10 to 50
o
C
Storage temperature range -20 to 60
o
C
Operating humidity range 35 to 85%R.H. (No condensation)
Withstand voltage 500 VAC for 1 minute between external terminals and F.E.
Environment
Insulation resistance 500 VDC, 10 M min. between external terminals and F.E.
Standard CE marking, UL (CSA), RoHS
Weight 170 g 175 g
: All unused connectors must have a seal cap fitted.
■Dimensions
•EX600-ED2-
