SMC Networks EX600 Series Opration Manual

-34-
EX※※-OMR1012
•SI unit parameters (1)
Parameter
setting
No. Parameter Definition Item Content
Default
setting
By
E.O.
By
W.S.
Enable Generates an error.
○
1
Power supply
for control and
input voltage
monitor
Generated error
per unit when
control and input
power supply
voltage goes over
approx. 29 V or
under 18 V.
Disable
Does not generate an
error.
○ ○
Enable Generates an error.
2
Power supply
for output
voltage
monitor
Generated error
per unit when
output power
supply voltage
goes over approx.
29 V or under 19 V.
Disable
Does not generate an
error.
○
○ ○
Enable Generates an error.
○
3
Short Circuit
Detection
Generates error
per unit when the
short circuit of the
valve is detected.
Disable
Does not generate an
error.
○ ○
Auto
Error is automatically
cleared when the short
circuit is fixed.
○
4
Restart after
short circuit
Restore the setting
of short circuit
detection error per
unit after the valve
short circuit is
cleared.
Manual
Even when the short
circuit is fixed, error is not
cleared until the power is
supplied again.
○ ○
Enable Generates an error.
5
Open Circuit
Detection
Generates error
per channel when
the disconnection
of the valve is
detected.
Disable
Does not generate an
error.
○
○ ○
Clear Turn off the output
○
Hold Hold the output
6
Output setting
during
communication
fault

1
Set output per
channel when
communication is
abnormal.
ForceON
Turn on the output
forcefully
○ ○
Clear Turn off the output
○
Hold Hold the output
7
Output setting
during
communication
idling

1

2
Output setting per
channel at the time
of communication
idling
ForceON
Turn on the output
forcefully
○ ○
