Diagnosis
By changing the diagnosis switch, the diagnostic data shown below is assigned to the head of input data of
the I/O map. (Refer to “Setting and adjustment” for setting the switch.)
Mode Diagnostic data Diagnostic size
0 No diagnostic data. 0 byte
1 System diagnosis + Unit diagnosis 4 bytes
