Unit/Channel diagnosis object (Class: 67h)
Instance Attribute Access Name Type Value
6Ch Unit diagnosis BYTE
0: No error, 1: Error
Bit0: The analogue value has fallen below the user set value.
Bit1: The analogue value has exceeded the user set value.
Bit2: The analogue input value has fallen below the set range.
Bit3: The analogue input value has exceeded the set range.
Bit4: The ON/OFF counter has exceeded the set value.
Bit5: The open circuit has been detected.
Bit6: The short circuit of the valve output or digital output
has been detected.
Bit7: The short circuit of the power supply for the
input/output device has been detected
6Eh
Channel diagnosis
Ch0 to Ch7
BYTE
0: No error, 1: Error
Bit0: There is an error in channel 0.
:
Bit7: There is an error in channel 7.
6Fh
Channel diagnosis
Ch8 to Ch15
BYTE
0: No error, 1: Error
Bit0: There is an error in channel 8.
:
Bit7: There is an error in channel 15.
70h
Channel diagnosis
Ch16 to Ch23
BYTE
0: No error, 1: Error
Bit0: There is an error in channel 16.
:
Bit7: There is an error in channel 23.
01h to
0Ah

1
71h
Get
Channel diagnosis
Ch24 to Ch31
BYTE
0: No error, 1: Error
Bit0: There is an error in channel 24.
:
Bit7: There is an error in channel 31.
1: The instance number 01h to 0Ah is allocated to the Unit No. from 0 to 9.
