SMC Networks EX600 Series Opration Manual

-69-
EX※※-OMR1012
Web Server
EX600 Web server functional overview
The Web server function is provided by the EX600-SEN5-X22.
The functions available vary depending on the mode.
Function Admin mode Monitor only mode
I/O Monitor Available Available
Diagnostic status monitor Available Available
Parameter setting Available Not available
Force I/O setting Available Not available
Connecting to a EX600-SEN5-X22 (Ex. Windows XP)
(1) Open a web browser on the PC.
(2) Type the IP address of EX600-SEN5-X22. (Ex. http://192.168.0.3.)
(3) The EX600 webpage should load after several seconds.
Note
This software operates correctly using Internet Explorer 9. If the functions do not operate
correctly with Internet Explorer 10 or later versions, then use Internet Explorer in compatibility
mode.
Note
Connect one SI unit to one PC.
