Details of Communication Format
4-1 HECR
4 Details of Communication Format
4.1 Temperature setting (without writing FRAM)
The host computer sets temperature of each Thermo-con. In this command, temperature setting data
is not written in FRAM. This data is invalidated by turning off power.
The setting range is from 10.0 to 60.0 deg.C. As 0.1 deg.C is the minimum unit, the number in the
hundredths place (10
-2
) should always be 0 (=30H). (When the value at every 0.01deg.C is input, it is
rounded off.)
Host →
STX
31H
Setting data
ETX
Check sum
CR
10
1
10
0
10
-1
10
-2
(H)
(L)
← Thermo-con
ACK
CR
<Specifying unit>
Host →
SOH
UT
STX
31H
Setting data
ETX
Check sum
CR
10
1
10
0
10
-1
10
-2
(H)
(L)
← Thermo-con
ACK
UT
CR
4.2 Reading setting temperature
As 0.1 deg.C is the minimum unit, the number in the hundredths place (10
-2
) is always 0 (=30H).
Host →
ENQ
31H
Check sum
CR
(H)
(L)
← Thermo-con
STX
31H
Setting data
ETX
Check sum
CR
10
1
10
0
10
-1
10
-2
(H)
(L)
Host →
ACK
CR
(Possible to omit)
