MODBUS communication function
HECR 5-14
5.10.2 Alarm flag
Each type of alarm which occurs in the product is read with the following assignment.
Name
Alarm flag 1,2
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Bit
Name
Explanation
Alarm flag 1
0
Unused
Alarm given off status
0= Not occurred
1= Occurred
1
ERR01 System error 1
2
ERR02 System error 2
3
ERR03 Back-up data error
4-10
Unused
11
ERR11 DC power supply failure
12
ERR12 Internal temperature sensor High temperature failure
13
ERR13 Internal temperature sensor Low temperature failure
14
ERR14 Thermostat alarm
15
ERR15 Abnormal output alarm
Alarm flag 1
0
ERR16 Low circulating flow rate alarm (option)
1
ERR17 Internal temperature sensor disconnection alarm
2
ERR18 External temperature sensor disconnection alarm
3
ERR19 Abnormal auto tuning alarm
4
ERR20 Low fluid level alarm
5-11
Unused
12
WRN Temperature upper limit
13
WRN Temperature lower limit
14
Unused
15
Unused
