MODBUS communication function
5-15 HECR
5.10.3 Control operation mode
The control operation mode is assigned as follows.
Name
Alarm flag 1
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
The operation mode with Modbus communication is displayed
as the figure on the right (Mode 0 = Operation stopped).
5.10.4 Circulating fluid set temperature
The circulating fluid set temperature can be set by specifying the circulating fluid target
temperature during Serial Remote mode.
If the temperature exceeds the upper limit of the circulating fluid set temperature range, the
circulating fluid target temperature is changed to the upper limit value. If it is lower than the lower
limit, the circulating fluid set temperature is changed to the lower limit value.
5.10.5 Setting of control mode
The operation can be controlled by sending the operation start command during Serial Remote
mode.
0=Stop 1=Start
5.10.6 Setting of the Upper Limit of the Output
The upper limit of the output can be set to restrict the power consumption. The power consumption
is reduced by 50% by setting the upper limit of heating to 50%.
Bit
Name
Explanation
0-2
Operation mode
000=Pump stop
001=Normal operation (Run)
010=Auto tuning start
011=Learning control
100=External tune control
3-15
Unused
-
M
O
D
E
R
e
m
:
0
P
V
<
2
3
.
0
o
C
#
1
S
V
3
0
.
0
o
C
