SMC Networks HECR Series Communications Manual

MODBUS communication function
HECR 5-16
5.11 Communication Format and Examples of Answers from
Thermo-con
Examples of commands and answers from the thermo-con
Address
Command
Slave
address
Host requirement
(Character)
Answer from thermo-con
(Character)
Content
0040
Reading internal
sensor temperature
1
:01 03 0040 0001 BB [CR][LF]
:01 03 02 09E1 10 [CR][LF]
Answer
“25.29 deg.C.”
0041
Reading external
Sensor temperature
1
:01 03 0041 0001 BA [CR][LF]
:01 03 02 09E1 10 [CR][LF]
Answer
“25.29 deg.C.”
0043
Reading status
1
:01 03 0043 0001 B8 [CR][LF]
:01 03 02 0005 F5 [CR][LF]
Run
with alarm
0044
Alarm flag 1
1
:01 03 0044 0001 B7 [CR][LF]
:01 03 02 8000 7A [CR][LF]
ERR15
0050
Control operation mode
1
:01 06 0050 0000 A9 [CR][LF]
:01 06 0050 0000 A9 [CR][LF]
Stop
:01 06 0050 0001 A8 [CR][LF]
:01 06 0050 0001 A8 [CR][LF]
Start
0051
Temperature setting
1
:01 06 0051 0BB8 E5 [CR][LF]
:01 06 0051 0BB8 E5 [CR][LF]
Set at
30.0 deg.C.
0052
Offset setting
1
:01 06 0052 0032 75 [CR][LF]
:01 06 0052 0032 75 [CR][LF]
Set at
0.50 deg.C.
