Piping specifications / Matrix table for option 1 and part numbers
Option 1
Piping specification
Description
Symbol
Part number
01
N01
W1
WF1
M5
C4
C6
Bracket A
A
ZS-24-A
Ο
Ο
Ο
Ο



Bracket B
B
ZS-24-B


Ο
Ο



Bracket D
D
ZS-24-D
Ο
Ο
Ο
Ο



Panel mount adapter
E
ZS-35-C
Ο
Ο





ZS-35-D


Ο
Ο
Ο
Ο
Ο
Panel mount adapter
+ Front protective cover
F
ZS-35-F
Ο
Ο





ZS-35-G


Ο
Ο
Ο
Ο
Ο
○Accessories 1 / Part numbers
Part number
Option 1
ZS-24-A
Bracket A with 2 mounting screws each of M3 x 5 L, M4 x 5 L
ZS-24-B
Bracket B with 2 mounting screws M4 x 5 L
ZS-24-D
Bracket D with 2 mounting screws each of M3 x 5 L, M4 x 5 L
ZS-35-C
Panel mount adapter (piping specification: 01, N01)
ZS-35-D
Panel mount adapter (piping specification: W1, WF1, M5, C4, C6)
ZS-35-F
Panel mount adapter + Front protective cover (piping specification: 01, N01)
ZS-35-G
Panel mount adapter + Front protective cover (piping specification: W1, WF1, M5, C4, C6)
