SMC Networks ISE40A

-45-
No.PS※※-OMM0007-H
Press the button to start copying.
The master Pressure switch
The slave Pressure switch
Sending/
Receiving
Copy
completed
(Red)
(Green)
Press the
button.
To complete the copy function,
press the and buttons
simultaneously for 1 second
or longer.
Setting of [F97] Copy function completed Measurement mode
: If the copy to the slave pressure switch is not completed, it is detected as a copy function sending/receiving error.
Press the and buttons simultaneously for 1 second or longer to return to measurement mode. Then, check the wiring and
specifications of the switch and retry the copy function.
The copy can be made continuously and
the copy ready status can be held even
if the power supply is turned off.
Press the and
buttons simultaneously
for 1 second or longer.
Press the button.
Flashing
(Red)
Flashing
(Green)
The copy ready status is held even if the power
supply is turned off.
