SMC Networks ITV1000 series Operation Manual



Errorindicatingfunction
Errorname
LED
display
Contentsoferror Countermeasure
Overrangeof
inputsignal

Inputsignal exceeds
the rated value
range.
Reduceinputsignaltowithin
theratedrangeandrestartthe
powersupply.

Reading or writing
errors occurred in
EEPROM.
Please execute "initialize
(refertoP16)"whenITVdonot
operate normally after
restartingthepowersupply.
Pleasecontactus,whenITVdo
not operate normally after
initialize.
Systemerror

Readingandwriting
errors occurred in
memory.
PleasecontactuswhenITVdo
not operate normally after
restartingthepowersupply.
Solenoidvalve
error

Solenoidvalve
failure.
Replacethesolenoidvalve.
Forthereplacementprocedure
contactSMC.
Overcurrent
error
Overcurrent errors
inswitchoutput
Pleaseusewithinstallingthe
load that the output current
becomesto80mADCorless.
Residual
pressureerror
Outofrangeerrorof
zeroclear
Pleaseoperate"zeroclear"
withintherangeof5%F.S..
Please operate "zero clear"
afterthesecondarypressureof
ITVisbecametoatmosphere.


―12―
