⑥ PressS-key.
⇔ (displayedalternately)
⑦
PressS-keyfor2secondsormore,thengooutfromdetailsettingmode.
(Selectthemenuwith△or▽keys,thenjumptoanotheritem.)

⑧ Lockkeys(refertoP8)

Relationbetweensettingofgainandresponsetime
Response Slow Quick
Setting
ofGAIN
  
〜

※Default: 



Sensitivitysetting
Normaloperationdoesnotrequiretheadjustmentofsensitivity.
Whenthesensitivityischanged,thecorrectionoperationofpressurechanges.
Whenthesensitivityischangedtosharp,thehuntingofpressuremightbeoccurred.
And, when the sensitivity is changed to dull, there is a possibility that
staggeringofgradualpressureoccur,becausethepressurecorrectionbecome
lower.

No Keyoperation LEDDisplay
①
Unlockkeys(refertoP8)
②
PressS-keyfor2secondsormore,thengotodetailsettingmode.
③
To"F02"byusingthe △and▽
keys.
⇔ (displayedalternately)
④ PressS-key. 
⑤
SettheSENSITIVITYbyusingthe△
and▽keys.
(blinkandchangethemostrightdigit)
⑥ PressS-key.
⇔ (displayedalternately)
⑦
PressS-keyfor2secondsormore,thengooutfromdetailsettingmode.
(Selectthemenuwith△or▽keys,thenjumptoanotheritem.)

⑧ Lockkeys(refertoP8)

Relationbetweensettingandsensitivity
Sensitivity Sharp  Dull
Settingofsensitivity
  
※Default: 
―14―
