SMC Networks ITV1000 series Operation Manual

③ To"F99"byusingthe△and▽keys.
⇔ 
(displayedalternately)
④ PressS-key.
flashesonthedisplay）
⑤
Press△andSkeysfor5secondsormore.
(pressS-keyto③)
isdisplayed
⑥
"Initialize" is executed, after 5
seconds.
（Releasekeystilllessthan5seconds
to④）
Turningofffor1second
⑦
Returnstothestateimmediatelyafterturningonofthepowersupply.
(keysarelocked)



LED display

TherangeoftheLEDpressuredisplayisdifferentaccordingtothe
pressurerangeandtheunitofthedisplay.

unit ITV※01※ ITV※03※ ITV※05※ ITV209※
MPa ｡020〜.120 ｡100〜.600 ｡180〜.A80 -
Kgf/cm
2
0｡20〜.120 1｡00〜6.00 1｡80〜A.80 -
bar 0｡20〜.120 1｡00〜6.00 1｡80〜A.80 -
PSI 3｡0〜18.0 14｡0〜84.0 -26〜156 -
kPa -20〜120 -100〜600 -180〜A80 16〜-96
(note1)：Themark"｡"isblinkingthedecimalpoint,anditisshownaminus.
(note2)：Whenthedigitoverflows,thefollowingof"9"aresubstitutedby"A".
(example:Thefollowingof999(kPa)aredisplayedasA00(kPa),andit
shows1000kPa.)
(note3)：Whenthedisplayexceedsthelowerboundvalue,"
"isdisplayed.
(note4)：Whenthedisplayexceedstheupperboundvalue,"
"isdisplayed.





RefertotheSMCwebsite(URL
http://www.smcworld.com)formoreinformation
abouttroubleshooting.
Thisoperationmanualreferstoallstandardtypesandispartiallyapplicable
tospecialmodels.
Thisoperationmanualissubjecttochangewithoutpriornoticeoranyobligation
onthepartofthemanufacturer.
―16―
