！ CAUTION
Take the following steps to avoid
malfunctionduetonoise.
1) Installalinefilteretc.totheACpower
linetoreduce/eliminatepowersupply
noise.
2) Avoid malfunction due to noise by
installingthisproductanditswiring
awayfromstrongelectricfields,suchas
thoseofmotorsandpowerline,etc.
3) Besuretoimplementprotective measures
againstloadsurgeforinductionloads
(solenoidvalves,relaysetc.).
4) Turn off the power supply before
installingorremovingtheconnector.
Please note that the right angled cable
connectordoesnotrotateandislimitedto
onlyoneentrydirection.

―4―
