C-1
A
PPENDIX
C
S
PECIFICATIONS
IEEE Standards
IEEE 802.3 10 BASE-T Ethernet
IEEE 802.3u 100 BASE-TX Fast Ethernet
IEEE 802.3, 802.3u, 802.11g, 802.1D
LAN Interface
4 RJ-45 10 BASE-T/100 BASE-TX ports
Auto-negotiates the connection speed to 10 Mbps Ethernet or 100 Mbps
Fast Ethernet, and the transmission mode to half-duplex or full-duplex
WAN Interface
1 RJ-45 port
Indicator Panel
Power, WAN, Online, WLAN, LAN 1~4, WPS
Dimensions
188 x 133 x 33 mm (7.40 x 5.24 x 1.30 in)
Weight
0.285 kg (0.764 lbs)
Input Power
9 V 1 A
Power Consumption
8 Watts maximum
