ISP S
ETTINGS
2-5
The Barricade contains the following ports and buttons:
ISP Settings
If you are not sure of your connection method, please contact your
Internet Service Provider. There are several connection types to choose
from: Static IP, DHCP, PPPoE, PPTP and L2TP.
Note: If using the PPPoE option, you will need to remove or disable any
PPPoE client software on your computers.
Item Description
LAN Ports Fast Ethernet ports (RJ-45). Connect devices on your local
area network to these ports (i.e., a PC, hub, switch or IP set
top box).
WAN Port WAN port (RJ-45). Connect your cable/xDSL modem line to
this port.
Reset Button Use this button to reset the power and restore the default
factory settings. To reset without losing configuration settings,
see “Reset” on page 4-66.
Power Inlet Connect the included power adapter to this inlet.
Warning: Using the wrong type of power adapter may cause
damage.
WPS Button
(on top panel)
Press this button for over 4 seconds to start using the WPS.
