-22-
No. ZK2-OM01301
4. Piping
(1) Allow a sufficient margin of tube length when piping, in order to prevent twisting, tensile, moment loads,
vibration or impact being applied to the tubes and fittings.
This can cause damage to the tube fittings and crushing, bursting or disconnection of tubing.
(2) Piping to the product is assumed to be static piping.
If the tube moves, it may become worn, elongated or torn due to tensile forces, or disconnected from the
fitting. Ensure the tube is in a static condition at all times before using.
(3) Prevent the connected tube from being rotated.
If the fittings are used in this way, the fitting may be broken.
(4) Do not lift the product by holding the piping after the tube is connected to the vacuum (V) port.
Otherwise, the filter case and/or the One-touch tube fitting will be damaged.
