SMC Networks ZL112A Series User Manual

Document No.ZL-OM01001
- 8 -
Names of Parts
With valves
Port block
Digital vacuum
pressure switch
Vacuum pressure gauge
Vacuum port
adapter
With port exhaust
With digital vacuum
pressure switch
With Vacuum
pressure gauge
With Vacuum port adapter
Exhaust port
Vacuum pressure
detection port
Supply ( P ) Port
Vacuum ( V ) Port
Suction cover
Silencer case ( Exhaust )
Without valve
Release valve
Supply valve
Vacuum break flow
adjusting needle
Lock nut
