Available Mounting Options
Series Bracket A Bracket B Bracket C Panel mount
20
앬앬
—
앬
20A
앬앬
—
앬
20B
앬앬
—
앬
20C
앬
—
앬앬
Bracket A
Bracket C
Bracket B
Panel mount
For General Fluids ZSE20C(F)/ISE20C(H)
p. 19
The bracket confi guration allows for mounting in four orientations.
Mountable side by side both
vertically and horizontally
One opening!
· Reduced panel fi tting labour
· Space saving
Mounting example
Mounting
example
Mounting example
Stainless diaphragm
Leakage
Enclosure: IP65
Oil-free (Single-layer diaphragm structure)
Sensor unit: Stainless steel 630
Fitting parts:
Stainless steel 304
A stainless steel 316L option is also available for the sensor unit and fi tting parts.
1 x 10
-10
Pa·m
3
/s
<Face seal and compression fi tting>
1 x 10
-5
Pa·m
3
/s
<Threaded type (R, Rc, NPT, G)>
¡Water
¡Hydraulic fl uid (JIS-K2213)
¡Silicone oil (JIS-K2213)
¡Lubricant (JIS-K6301)
¡Fluorocarbon
¡Argon
¡Carbon dioxide
¡Air-containing
drainage
¡Nitrogen
Welded structure for sensor units and fi tting parts
Select from a face seal or compression fi tting.
Mounting
Applicable Fluid Examples
Compression Face seal Confirmation
of the atmos-
pheric pres-
sure of a load
lock chamber
4
High-Precision Digital Pressure Switch ZSE20첸(F)/ISE20첸 Series
3-Screen Display
