SMC Networks ZSE20 Series User Manual

Other Sub Screen Display
The peak value or bottom value, or both values can be displayed
on one screen!
∗ Peak and bottom values are maintained even if the power supply is cut.
∗ A combination of the displays shown above and the set values can be
displayed on the 2 sub screens.
Level bar
display
Positive pressure range Compound pressure range Vacuum pressure range
Rated range display
psi barMPa
Pressure unit display
kPa
Hysteresis mode Window comparator mode
Output mode/Output type display
Normal outputNormal output Reversed outputReversed output
Peak value Bottom value Peak value/Bottom value
Label
(Peak)
Peak value
Label
(Bottom)
Bottom
value
Peak value
Bottom
value
앬 Copy function
The settings of the master sensor can be
copied to the slave sensors.
앬 Power-saving function
Power consumption is reduced by
turning off the monitor.
앬 Secret code setting function
The key-lock function keeps unau-
thorized persons from tampering
with the settings.
앬 Auto-shift function
This measures the pressure at the time of
external input and uses it as a reference to
correct the on-off point of the switch.
앬 MPa/kPa switch function
Vacuum, compound, and/or positive
pressure can be displayed in MPa or
kPa.
(Only the displayed values are changed; the accuracy remains the same.)
1/1000 1/100
앬 Display resolution switch function
Reduces monitor fl ickering
Convenient Functions
Series Current consumption Reduction rate
∗
1
20 25 mA or less
Approx. 60 %
reduction
20A
35 mA or less
Approx. 40 %
reduction
20B
20C
∗1 In power-saving mode
Master sensor
1 unit
Slave side 씮
2 units 10 units
CopyCopy
········
Improved Operability
앬 Lightweight: Max. 21 g lighter
(When an M5 female thread is used.)
ZSE/ISE40, 80 Series
앬 Compact: Max. 17.5 mm shorter
(When an M5 female thread is used.)
Compact & Lightweight
Functions Copy function Auto-shift function Secret code setting function Power-saving function Resolution switch function MPa/kPa switch function
20 ——
앬앬앬앬
20A
앬앬앬앬앬앬
20B
앬앬앬앬앬앬
20C
앬앬앬앬앬앬
p. 13, 21
Improved Installability
Grommet type
Connector type
Wiring is possible after piping has
been connected.
ZSE30A(F)/ISE30A
ZSE20(F)/ISE20
ZSE20(F)/
ISE20
ZSE30A(F)/
ISE30A
17.5 mm (20/20A)
Lead wire
M5 female
thread
M5 female
thread
3
High-Precision Digital Pressure Switch ZSE20첸(F)/ISE20첸 Series
3-Screen Display

SMC Networks ZSE20 Series Specifications

General

Brand	SMC Networks
Model	ZSE20 Series
Category	Switch
Language	English
