Delay time selection
Select from • 1.5 ms or less
• 20 ms • 100 ms • 500 ms
• 1000 ms • 2000 ms • 5000 ms
Display colour selection
Select from
• ON
Green
/OFF
Red
(OUT1 or OUT2)
• ON
Red
/OFF
Green
(OUT1 or OUT2)
• Normally
Red
/Normally
Green
Mode selection
Output mode selection
Select from • Hysteresis mode
• Window comparator mode
• Error output • Output OFF
Normal or reversed
output selection
Select from • Normal output
• Reversed output
Set value (Threshold
value) setting
• Adjust the numerical value.
Hysteresis value
setting
• Adjust the numerical value.
3 Setting Modes
Select the setting mode that best meets your needs.
3-Step Setting
Mode
Setting Complete Setting Complete Setting Complete
Simple Setting
Mode
Function
Selection Mode
Press the
button once.
Press the button for
between 1 and 3 seconds.
Press the button for
between 3 and 5 seconds.
Settings
• Threshold value setting
or
• Hysteresis value setting
Simple
Higher
function
• Output mode selection
• Selection of normal or reversed
• Threshold value setting
•
Hysteresis value setting
• Delay time selection
•
Display colour selection
• Threshold value setting
• Hysteresis value setting
• Delay time selection
∗ For 1 output
2
High-Precision Digital Pressure Switch ZSE20첸(F)/ISE20첸 Series
3-Screen Display

SMC Networks ZSE20 Series Specifications
