Brown DC (+)
Black OUT
Blue DC (–)
FUNC
Load
+
–
Load
Brown DC (+)
Black OUT
Blue DC (–)
FUNC
12 to
24 VDC
Brown DC (+)
Black OUT1
White OUT2
FUNC
Blue DC (–)
Load
Load
+
–
12 to
24 VDC
Brown DC (+)
Black OUT1
White OUT2
FUNC
Blue DC (–)
Load
Load
+
–
12 to
24 VDC
12 to
24 VDC
Main circuit
Main circuit
Main circuit
Main circuit
Internal Circuits and Wiring Examples
Max. 80 mA
Residual voltage 1 V or less
Max. 28 V, 80 mA
Residual voltage 1 V or less
Max. 80 mA
Residual voltage 1 V or less
Max. 28 V, 80 mA
Residual voltage 1 V or less
Z/ISE30A
(
F
)
Output
NPN (1 output)
N
NPN (2 outputs)
A
PNP (2 outputs)
B
PNP (1 output)
P
Note) The FUNC terminal is connected using a dedicated lead wire (ZS-38-5L or ZS-38-U) when the copy function is used. (Refer to “Copy function” on page 10.)
Series ZSE30A
(
F
)
/ISE30A
Load
Load
Brown DC (+)
Black OUT1
Blue DC (–)
FUNC
White OUT2
+
–
12 to
24 VDC
Load
Load
Brown DC (+)
Black OUT1
Blue DC (–)
FUNC
White OUT2
+
–
12 to
24 VDC
Load
Load
Brown DC (+)
Black OUT1
Blue DC (–)
FUNC
+
–
12 to
24 VDC
White OUT2
Load
Load
Brown DC (+)
Black OUT1
Blue DC (–)
FUNC
+
–
12 to
24 VDC
White OUT2
Main circuit
Main circuit
Main circuit
Main circuit
Max. 28 V, 80 mA
Residual voltage 1 V or less
Analogue current output
Max. load impedance:
Power supply voltage 12 V: 300 Ω
Power supply voltage 24 V: 600 Ω
Min. load impedance: 50 Ω
Max. 80 mA
Residual voltage 1 V or less
Analogue current output
Max. load impedance:
Power supply voltage 12 V: 300 Ω
Power supply voltage 24 V: 600 Ω
Min. load impedance: 50 Ω
Max. 28 V, 80 mA
Residual voltage 1 V or less
Analogue voltage output
Output impedance: Approx. 1 kΩ
Max. 80 mA
Residual voltage 1 V or less
Analogue voltage output
Output impedance: Approx. 1 kΩ
NPN (1 output) + Analogue voltage output
C
PNP (1 output) + Analogue voltage output
E
NPN (1 output) + Analogue current output
D
PNP (1 output) + Analogue current output
F
Note) The FUNC terminal is connected using a dedicated lead wire (ZS-38-5L or ZS-38-U) when the copy function is used. (Refer to “Copy function” on page 10.)
Series ZSE30A
(
F
)
/ISE30A
2-Colour Display
High-Precision Digital Pressure Switch
