Instructions for the installer
36
Twin oven model
The appliance comes with a terminal board on the back for electrical
hook-up (see following diagram). To open the terminal board cover,
remove the fixing screw and raise the cover.
1 - For operation on 220-240V ∼ : use a
three-pole H05RR-F type cable (3 x 2.5
mm
2
). This is the connection carried out
in the factory.
2 - For operation on 220-240V3 ∼ : use a
four-pole H05RR-F type cable (4 x 1.5
mm
2
).
3 - For operation on 380-415V2N ∼ : use a
four-pole H05RR-F type cable (4 x 1.5
mm
2
).
The cable end to be connected to the
appliance must be provided with an ground
wire (yellow-green) at least 20 mm longer.
