User instructions
1. Description of the controls
1.1 Front panel
All the dishwasher control are grouped on the front panel.
1 ON/OFF
BUTTON
2 SELECTION PROGRAMS
BUTTONS
(P1...P5)
3 DELAY PROGRAM
BUTTON (on some models only)
½ LOAD WASH
BUTTON (on some models only)
4
"3/1" OPTION
BUTTON (on some models only)
5 START/PAUSE
BUTTON
6 POWER ON
LIGHT
7 PROGRAMS
LIGHTS
8 DELAY PROGRAM
LIGHTS (on some models only)
9 ½ LOAD WASH
LIGHT (on some models only)
10 PHASES
/
PROGRAM
LIGHTS
11 NO SALT
LIGHT (on some models only)
12 NO RINSE AID
LIGHT (on some models only)
13
RECESSED DOOR HANDLE
