Installation
41
EN
General information
This appliance may be installed next to
walls, one of which must be higher than the
worktop, at a minimum distance of 50 mm
from the side of the appliance, as shown in
figures A and C relative to the installation
classes.
Any wall units positioned above the
worktop must be at a minimum distance of
at least 600 mm. If a hood is installed
above the cooktop, refer to the hood
instruction manual to ensure the correct
clearance is left.
Depending on the type of installation, this
appliance belongs to classes:
A - Class 1 (Free-standing appliance)
B - Class 2 subclass 1 (Built-in appliance)
C - Class 2 subclass 1 (Built-in appliance)
The appliance must be installed by
authorised persons and according
to the regulations in force.
If the appliance is installed on a
raised platform, secure it using
suitable fastening systems. DO
NOT MODIFY THIS APPLIANCE.
