Instructions for the installer
60
7.2 Fixing to the supporting structure
Carefully position the supplied insulating seal
on the outer edge of the hole on the top hob,
as indicated in the figure alongside. Try and
make it stick to the whole surface by applying
light hand pressure.
The seal must be placed at a distance of 3-4
mm from the edge of the hole in the top.
Carry out this operation by supporting the hob
on the isolating seal and using screws and
clamping brackets to fix the hob to the
support structure, in order to obtain the
complete flatness.
Carefully trim the surplus away from edge
beyond the seal.
