Instructions for the installer
34
7. POSITIONING ON THE HOB TOP
This is a cat. 3 appliance (built-in).
The following operation requires building and/or carpentry work and must
therefore be carried out by a competent tradesman.
Installation can be carried out on various materials such as masonry, metal,
solid wood or plastic laminated wood as long as they are heat-resistant (T
90°C).
7.1 Built-in dimensions
DISTANCES A B C D E H
MINIMUM 292 mm. 494 mm. 20 mm. 110 mm. 50 mm. 750 mm.
MAXIMUM 292 mm. 494 mm. 70 mm. - - -
