Instructions for the user
30
5. USING THE HOB
5.1 Lighting the hob burners
Before lighting the hob burners, check that the flame-spreader crowns are
correctly in place with their respective burner caps, making sure that the holes A
in the flame-spreaders are aligned with the igniters and thermocouples.
For dual burner UR2, place and lock caps G and F perfectly on burner D. This
latter, in turn, must be placed and locked into the base B (use pins C as a
reference). Rack H is for use with woks.
The burner controlled by each knob is shown next to the
knob. The appliance is equipped with an electrical ignition
device. Simply press the knob and turn it anti-clockwise to
the maximum flame symbol , until the burner lights.
On valved models, once the burner is lit, keep the knob pressed for a few
seconds to give the thermocouple time to heat up. The burner may go out when
the knob is released: in this case, the thermocouple has not heated up
sufficiently.
Wait a few moments and repeat the operation, keeping the knob pressed for
longer. This is not necessary on burners that are not equipped with a
thermocouple.
Once the burner is lit, the flame can be adjusted as required.
Always check that the control knobs are in the O (off) position when you finish
using the hob.
If the burners should go out accidentally, after about 20 seconds a safety device
will be tripped, cutting off the gas supply, even if the gas tap is open.
