Smeg PLA8743X - Adjusting the Upper Rack

Rev 0.0 31
USER INSTRUCTIONS
EN
Adjusting the upper rack
Version A (see fi g. 4-15): the upper rack can be adjusted in two positions,
according to the user’s needs and according to the height of the dishes in the
lower rack. Proceed as follows:
pull out the right-hand rack guide. Remove the stop (ref. A fi g. 4-15) after
releasing the tabs (ref. B fi g. 4-15) (fi rst release the upper tab and then the
lower one);
pull out the left-hand rack guide and remove the corresponding stop, just as
you did for the right-hand rack guide;
remove the rack from the guides;
fi t the upper or lower pair of wheels (ref. c fi g. 4-15) into the guides, depend-
ing on the setting required;
return the guide stops to their original positions (ref. d fi g. 4-15) (fi rst attach
the lower tab and then the upper one).
B
B
AC
D
•
•
•
•
•
Fig. 4-15
