Rev 0.0 33
USER INSTRUCTIONS
EN
Version C (see fi g. 4-17): the upper rack can be set in three different positions
on both sides. The rack must be level on both sides.
To raise the rack (ref. A fi g. 4-17), lift it with the two handles (e.g.: ref. B fi g. 4-
17) to the fi rst or second catch depending on the height required. To lower it
(ref. c fi g. 4-17), pull up the two release levers (e.g.: ref. D fi g. 4-17). This is also
possible with the rack loaded, but in this case when lowering the rack it should
be held steady with one hand to avoid knocking the dishes.
A
B
D
C
Fig. 4-17
