Rev 0.0 29
INSTALLATION INSTRUCTIONS EN
Fig. 5-23
Attach the door panel: fi t the hooks into their slots on the dishwasher and allow
the panel to slide downwards and slip in to place (see fi g. 5-23).
1
2
Secure the door to the panel with the supplied screws. The panel must have a
minimum thickness of 20 mm (25/32”) (see fi g. 5-24).
Fig. 5-24
