INSTALLATION INSTRUCTIONS EN
Attach the door panel: fi t the hooks into their slots on the dishwasher and allow
the panel to slide upwards and slip into place (see fi g. 5-31).
1
2
Fig. 5-31
Secure the door to the panel with the supplied screws. The panel must have a
minimum thickness of 20 mm (25/32”) (see fi g. 5-32).
Fig. 5-32
