Smeg SAP306X-9 User Manual

Instructions for the User
35
9.3 Removing the door seal
For multifunction models only:
To permit thorough cleaning of the
oven, the door seal may be removed.
There are fasteners on all four sides to
attach it to the edge of the oven. Pull
the edges of the seal outwards to
detach the fasteners.
9.4 Removing the internal glass panels
The glass in the door should always be kept thoroughly clean. To facilitate
cleaning, it is possible to remove the door (see 9.2 Removing the door) and
place it on a canvas, or open it and lock the hinges in order to extract the glass
panels.
The glass panels of the door can be completely removed by following the
instructions provided below.
Warning: before removing the glass panels, make sure that at least one of the
door's hinges has been locked in the open position as described in “9.2
Removing the door”. This operation may have to be repeated during the glass
removal process if the door is accidentally freed.

Smeg SAP306X-9 Specifications

General

Type	Built-in
Oven Type	Electric
Energy Input	Electric
Width	60 cm
Cleaning System	Vapor Clean
Cavity Material	Enamel
Temperature Control	Electronic
Minimum Temperature	50 °C
Maximum Temperature	250 °C
Timer	Yes
End of Cooking Acoustic Alarm	Yes
Controls	Knobs
Number of Glass Door	3
Soft Close	Yes
Energy Efficiency Class	A
Voltage	220-240 V
Frequency	50/60 Hz
Control Type	Electronic
Number of Cooking Levels	3
Thermostat	Yes
Temperature Range	50 - 250°C
Grill	Yes
Defrost Function	Yes
Timer Type	Electronic
Cooling Fan	Yes
Light	Yes
Door Glazing	Triple
Color	Stainless Steel
Energy Consumption in Conventional Mode (MJ)	3.1 MJ
Energy Consumption in Conventional Mode (KWh)	0.9 kWh
Energy Consumption in Forced Air Convection (MJ)	2.7 MJ
Energy Consumption in Forced Air Convection (KWh)	0.75 kWh
Dimensions (H x W x D)	59.5 x 59.5 x 56.5 cm
