38
Instructions for the user
Replacing the glass:
• Replace the panes in the
opposite order to which they
were removed. The middle
glass pane must be inserted
first on the front part, exactly on
the second level (figure A), and
then inserted on the back, again
in the second level (figure B).
• Pay careful attention to the four
rubber strips on the sides
(figure C). These must be
lowered during the insertion of
the middle glass pane, acting as
a seal between the frame and
the pane of glass.
• Replace the internal glass pane
inserting it on the third level in
the same way as described for
the middle pane. (figure A , B).
Warning: replace the glass panes in the same order and in the same
direction that they were removed. Finally, if the door was not removed,
unlock the hinges and close it.
