55
Instructions for the user
7.3.3 Removing the self-cleaning panels
Remove all the accessories from the oven and carry out the following
operations:
1 Remove the side racks (fig.1);
2 Slide out the side panels “F” and “G” (fig. 2);
3 Extract the rear panel “A” after first unscrewing the threaded rings
“C” (fig. 2);
4 Reassemble the panels by returning them to their original
conditions.
1) 2)
7.4 Removing the door
7.4.1 With type 1 movable levers
With the door completely open, lift the levers A until they touch the
hinges B and take hold of the two sides of the door with both hands
close to the hinges. Raise the door to an angle of about 45° and remove
it. If the hinges have not locked, repeat the operation, raising the levers
A and keeping the door slightly raised. To reassemble, fit the hinges B
into their grooves, then lower the door into place, ensuring that it
remains fitted into the grooves C, then lower the levers A.
