Smeg SI2M7643B - Hob Assembly Specifications; Assembly Dimensions and Clearances

Assembly
min.
50mm
min.
500mm
R 5mm
min.
55mm
560
+1
mm
490
+1
mm
min.
28 mm
min.
12 mm
min. 60mm
If the appliance is installed
above a drawer, the hob
ventilation can warm up the
items stored in the drawer
during the cooking process.
19
