Installation
69
EN
Hob seal
To prevent leakage of liquid between the
frame of the hob and the countertop, place
the adhesive seal provided along the entire
outer edge of the hob before assembly.
Flush built-in model
For this kind of hobs additional milling is
needed in the recessed hole if you wish to
install the hob flush with the work surface.
A B C D E
min.
50
min.
460
min.
750
20-60
min.
50
Do not use silicone to secure the
hob. This would make it impossible
to remove the hob, if necessary,
without damaging it.
L X Y G H
900 860 490 904 514
A B C D E
min.
50
min.
460
min.
750
20-60
min.
50
