WIRING DIAGRAM PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 22-003 Ammeter 1
2 76-269 Power Wire to Hour Meter 1
3 12-017 Hour Meter 1
4 76-259 Ground Wire for Hour Meter 1
5 76-260 Ground Wire for Ignition Switch 1
6 34-146 Panel Mount Circuit Breaker 1
34-145 Circuit Breaker Boot 1
7 13-288 Key Switch with Hardware (Kohler #25 099 04) 1
76-310 Key Switch 1
8 50-359 Warning Indicator Light 1
9 Oil Sender (Part of Engine)
10 Ignition Module (Part of Engine)
11 Fuel Shut-Off Solenoid (Part of Engine)
12 Rectifier ( Part of Engine)
13 Starter (Part of Engine)
14 22-073 Battery 1
48-166 Battery Hold-down 1
15 48-147 Black Battery Cable 1
16 48-157 Red Battery Cable 1
8892-21 Hose Wrap
1
/
4
x 40 1
17 Wire With Fuse (Part of Engine)
Fuse AGC 30
18 76-337 Electric Clutch 1
19 15-314 Toggle Switch 1
15-472 Switch Boot 1
20 14-292 Seat Switch 1
* 76-392 Wire Harness (Includes all wire color with *) 1
