3
Introduction
SPECIFICATIONS FOR SWEEP STAR 48 HIGH LIFT
WEIGHTS AND DIMENSIONS HIGH LIFT
Length 121" (307 cm)
Width 60" (153 cm)
Height with Hopper Down 63" (160 cm)
Height with Hopper Up 126" (320 cm)
Wheel Base 70" (179 cm)
Weight 1800 lbs(818 kg)
SOUND LEVEL (DBA)
At ear level 90 dba
At 3 ft (0.914 m) 91 dba
At 30 ft (9.14 m) 76 dba
ENGINE
Make Kohler
Model# CH25
Type / Spec# CH730-0100
Horsepower 25 Hp (18.6 kw)
Fuel Unleaded 87 Octane
Gasoline Minimum
Cooling System Air Cooled
Lubrication System Full Pressure
Alternator 15 Amp
WHEELS & TIRE Front: One 18 x 9.50 x 8 Multi-rib
Rear: Two 24 x 12.00 x 12 NHS (20 psi max)
Castor: 9 x 3.50 - 4
BRAKES Dynamic Through Hydrostat
PARK BRAKE Hand Operated Lever, Discs on Rear Axle
SPEED
Forward Speed 0 to10 mph (0-16kph)
Reverse Speed 0 to 4 mph (0-6 kph)
BATTERY 12 Volt Automotive IBS type 45-50
Cold Cranking Amps 48 minimum
Ground Terminal Polarity Negative (-)
Maximum Length 9" (23cm)
Maximum Width 5.38" (14cm)
Maximum Height 9" (23cm)
FLUID CAPACITY
Crankcase Oil See Engine Manual
Fuel 5 gallon (19 liters)
Hydraulic Fluid 5 gallon (19 liters)
Grade of Hydraulic Fluid SAE 10W-40 API Service SG Motor Oil
OPTIONAL EQUIPMENT
48-084 48" Brush Reel Kit (includes pillow blocks and pulley drive)
48-085 48" Finger Reel Kit (includes pillow blocks and pulley drive)
48-120 Dust and Filtration pack - High lift
