Smithco SweepStar 48 - Hydraulic Diagram

15
Diagrams
HYDRAULIC DIAGRAM PARTS LIST (HIGH LIFT)
REF# PART# DESCRIPTION QUANTITY
1 76-242 Hydraulic Cylinder 2
2 48-012 Hydraulic Hose 1
3 48-013 Hydraulic Hose 1
4 48-137 Wheel Motor 2
5 34-057 Tee 2
6 48-015 Hydraulic Hose 4
7 8810-19 Hose
5
/8 ID 1
18-077 Hose Clamp 2
8895-22 Hose Wrap 22" 1
8 48-016 Hydraulic Hose 2
8895-44 Hose Wrap 44" 2
9 76-322 Hydrostatic Pump 1
10 76-323 Gear Pump (replacement; no repair) 1
11 48-020 Hydraulic Hose 1
. 8895-40 Hose Wrap 40" 1
12 8810-07 Hose
5
/8 ID x 7" 1
18-077 Hose Clamp 2
8895-8 Hose Wrap 8" 1
13 8832-19 Hose
3
/4 ID x 19" 1
18-040 Hose Clamp 2
8895-22 Hose Wrap 22" 1
14 48-083 Oil Filter 1
48-083-01 Filter Element (replacement only) 1
15 48-135 Oil Tank 1
16 48-062 Hydraulic Hose 1
8895-67 Hose Wrap 67" 1
17 34-105 Oil Cooler 1
18 48-021 Hydraulic Hose 1
8895-92 Hose Wrap 92" 1
19 48-018 Hydraulic Hose 1.
8895-73 Hose Wrap 73" 1
20 76-115 Hydraulic Hose 2
8895-74 Hose Wrap 74" 2
21 76-023 3-Bank Hydraulic Valve 1
22 48-019 Hydraulic Hose 2
8895-54.5 Hose Wrap 54.5" 2
23 75-634 Hydraulic Cylinder 1
24 48-017 Hydraulic Hose 1
8895-73 Hose Wrap 73" 1
25 18-173 Tee
3
/8 Junction Union 2
26 48-014 Hydraulic Hose 1
27 75-714 Hydraulic Cylinder 1
28 27-065 Hydraulic Hose 1
