Smithco SweepStar 48 - Hydraulic Lift Cylinder; Hydraulic Lift Cylinder Drawing

31
Parts
HYDRAULIC LIFT CYLINDER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 76-242 Hydraulic Cylinder 1
76-242-01 Seal Kit 1
2 23-167 Elbow 2
3 76-242-02 Clevis pin with Clip 2
INCLINOMETER PARTS LIST
REF# PART # DESCRIPTION QUANTITY
1 HSM-10-32-075 Machine Screw #10 -32 x
3
/
4
2
HNFL-10-32 Flange Whiz Lock Nut #10 -32 2
2 76-373 Inclinometer Bracket 1
3 HSM-10-32-100 Machine Screw #10 - 32 x 1 2
HNFL-10-32 Flange Whiz Lock Nut #10 -32 2
4 76-372 Inclinometer 1
